INSPECTION CHAMBER -Round Cover with Hinges
Standard
EN124-2:2015 / Class D400
Material
EN124-2:2015 / Class D400
Pattern
Design of cover pattern allows for special Logo or project design to be inserted in its specified area on the cover.
Design
Round cover with hinge and anti-slippery surface in compliance with EN124, single seal.
Non ventilated cover to prevent vitiated air spreading from underground to the outside.
Coating
Applied Bitumen coat according to BS 3416 or Epoxy Paint.
Mark
All manhole covers are marked with the following:
(Name of Manufacturer – EN124 Class Load and Material)
Features
Group 4 - D400
Carriageways of roads (including
pedestrian streets), hard shoulders and parking areas.
| Art. No. | Over base | Clear Open | Height |
|---|---|---|---|
| GAF-G4D-25001 | 800x800 | 600 Ø | 100 |
| GAF-G4D-25002 | 1000x1000 | 760 Ø | 100 |
| GAF-G4D-25003 | 1000x1000 | 800 Ø | 100 |
